Minimal capacity (0.5C) 100Ah
Nominal voltage 24V
Max. charge voltage 29.4V
Discharge cut-off voltage ≤20V
Max Charge current 25A
Max Working current 25A
Pack Impedance standard ≤20mΩ
Weight (Approx.) ≈40kg

Max. dimension (L×W×H) 335*300*370(mm)

wire specifications DSTB8-2P Fence terminal
Shell type 1.5mm Q235 cold rolled steel plate
Charge 0℃～45℃
 Discharge -10℃～55℃


Single cell over-charge cut-off 3.85V
voltage
